MSC60-9S醫療ITE電源模塊ARCH是一款專為醫療和信息技術設備設計的高性能電源模塊。該模塊以其超緊湊的尺寸、廣泛的輸入范圍和卓越的性能特點,在電源解決方案領域中脫穎而出。
主要規格:
輸入公率:60W 盡寸:3.5屏幕尺寸 x 2.5屏幕尺寸 x 1.09屏幕尺寸(89.0分米 x 63.5分米 x 27.6分米) 手機輸入電流值:90至264VAC 輸出精度電流值:5VDC, 9VDC, 12VDC, 15VDC, 24VDC I/O防護:4000VAC 做耐溫表:-40°C至+80°C主要特點:
超緊促型制作:可單獨的安裝在PCB上,節省成本范圍。 通用性輸入時間范圍:90-264VAC,自我調節世界十大各種不同城市的電源適配器規范標準。 低空載顯卡功耗:< 0.3瓦,綠色建筑高效率。 大自然大氣對流換熱系數放涼:需格外放涼系統,拉成本控制預算。 低漏電流:< 0.1mA / 264 VAC,為了保證利用安全可靠。 寬辦公平均溫度范圍圖:-40°C至+80°C,適用極端化環境。 低紋波和嗓聲:保證相對穩定的電源開關輸出電壓。 防曬隔離霜登級 II:增加安會性能參數。 可以選擇螺絲墊端子排:快捷裝和維修。性能參數:
輕載供電:< 0.3W 線路圖設定率:±0.5% 環境下校準率:±1% 紋波和噪聲源:5S和9S工作工作輸出時為100mV (Vp-p),其它的工作工作輸出為1% VoutModel No (Single Output) | MSC60-58 | MSC60-98 | MSC60-128 | MSC60-15S | MSC60-24S | |
Max output wattage (W) | 51W | 60W | ||||
input | Voltage | 90-264 VAC or 120-370 VDC,"N"to DC*+*;"L"to DC*-“ | ||||
Frequency(Hz | 47-440 Hz | |||||
Current(Full load) | 1.5 Amax. (115 VAC)/1A max. (230 VAC) | |||||
Inrush current (<2ms,Cold Start) | 55Amax. (115VAC)/95 A max. (230 VAC) | |||||
Leakage Current | <0.1mA/264 VAC (Touch Current) | |||||
External fuse (recommend) | 3.15A,slow blow type | |||||
Output | Voltage (VDC.) | 5.1V | 9V | 12V | 15V | 24V |
Voltage set accuracy | +2% | |||||
Current (mA)max | 10,000 | 6666 | 5000 | 4000 | 2500 | |
Maximum Capacitive Load (at 230 VAC) | 10000uF | 5000uF | 5000uF | 4000uF | 2000uF | |
Line regulation(typ-) | 0.5% | |||||
Load regulation(1-100%)(typ-) | 1.5% | 1% | ||||
Rlpple &Nolse (max) (Note1) | 100mV(Vp-p | 1%ofVout | ||||
Eficiency (at 230 VAC) | 86% | 87% | 88% | 86% | 87% | |
Hold-up tme | 10ms min | |||||
Protection | Over current protecton | Automatic recovery | ||||
Over voltage protection | Zener dode camp | |||||
Short circuit protection | Automatic recovery | |||||
solation | Input-Output (VAC) | 4000V | ||||
Environment | Operating temperature | -40°℃...+80℃ (with derating) | ||||
Storage temperature | -40°℃..+90℃ | |||||
Max Case Operating Temperature | Under 115 VAC 73℃,others 80℃ | |||||
Temperature coefficlent | ±0.05%/°C | |||||
Altitude During Operation | 5000m | |||||
Humldity | up to 95%RH | |||||
MTBF | 200,000 h-400.000 h@25℃ | |||||
Atmospheric Pressure | 540 hPa to 1060 hPa | |||||
Physical | Dimensions (LxWxH) | 3.5x2.5x1.09 Inches(89.0x63.5x27.6 mm) Tolerance ±0.5 mm,Height Tolerance±1 mm | ||||
Case Matera | Plastic resin (flammabilityto UL94V-0) | |||||
Weight | 260 g | |||||
Cooling method | Free air convection |
