?SA產品超寬敞、薄型DC-DC轉型器PICO
發布的時間段：2022-11-09 16:58:16 挑選：1021
PICO的SA類別單輸送、高電壓DC-DC更換器建議選用超小規模封裝類型組件。SA系轉換成器遵循高效、性價比最高率和優質的阻抗設定功用，能在-25°C至+70°C的室溫范圍之內內事業，并不會現身不間斷調額和/或散熱。
癥狀
超小形議器機箱
帶體系化抽頭的單讀取
防護隔離、非穩壓、3W額定工作效率工作效率
1500Vdc輸人/打出防護
手機輸入過壓關掉
高率：至87%
苛求的環境下調準
低讀取紋波
高進入/打出防護
內部組織攝氏度保養
寬控制濕度：-25°C至+70°C
軟件應用
超聲檢查波會產生器
雪崩光電產品肖特基二極管
光電束偏差
光譜分析學
微電子發現器
電容器電池充電
如何消除靜電眼鏡
壓阻式器材
鄭州市立維創展信息技術是PICO工廠的代銷商。出具進口清關PICO主機開關電源適配器功能、軍用裝備主機開關電源適配器功能、高壓電主機開關電源適配器功能、中型箱式變壓器、MIL-PRF-21038/27外形尺寸電力低壓變壓器、智能電力低壓變壓器、400 MHz電業配電變壓器、MIL-STD-1553界面低壓配電變壓器、音頻軟件低壓配電變壓器、瓦數電感、小型瓦數電感、EMI電感、薄DC-直流電壓電信息模塊、警用DC-DC電源接口接口、磚塊DC-DC主機電源組件、高電壓DC-DC、AC-DC供電板塊、觸點開關交流電供電板塊、隔開供電板塊、飛機維修供電板塊等系統供電板塊和額定功率變換器。原廠軟件進口量，的質量切實保障，邀請詢問。
內容掌握PICO主機電源輸出模塊請彈框：//www.takasago.net.cn/brand/15.html
SERIES 5SA
Standard Models (25°C ambient, Vi, nom and Pout, Max.) |
PICO PART # | INPUT VOLTAGE
(Vdc) | OUTPUT
VOLTAGE | INPUT
VOLTAGE | MAX.
OUTPUT
CURRENT
(mA) | MAX.
OUTPUT
POWER
(W) | LOAD
EFFECT
(%) | EFF.
(%) | OUTPUT
RIPPLE
(%) |
Plug-In | Surface Mount | NOM | RANGE | O.V.
SHDN | NOM
(Vdc) | TOL
(%) | NO
LOAD
(mA) | FULL
LOAD
(mA) |
5SA100 | 5SA100SM | 5 | 4.5...5.5 | 6 | 100 | +/-3 | 65 | 695 | 30.0 | 3 | 5 | 86 | 0.8 |
5SA150 | 5SA150SM | 5 | 4.5...5.5 | 6 | 150 | +/-3 | 66 | 705 | 20.0 | 3 | 6 | 85 | 1.0 |
5SA200 | 5SA200SM | 5 | 4.5...5.5 | 6 | 200 | +/-3 | 65 | 690 | 15.0 | 3 | 8 | 87 | 1.3 |
5SA250 | 5SA250SM | 5 | 4.5...5.5 | 6 | 250 | +/-3 | 67 | 690 | 12.0 | 3 | 7 | 87 | 1.6 |
5SA300 | 5SA300SM | 5 | 4.5...5.5 | 6 | 300 | +/-3 | 66 | 700 | 10.0 | 3 | 6 | 85 | 1.3 |
5SA350 | 5SA350SM | 5 | 4.5...5.5 | 6 | 350 | +/-3 | 67 | 700 | 8.6 | 3 | 6 | 85 | 1.4 |
5SA400 | 5SA400SM | 5 | 4.5...5.5 | 6 | 400 | +/-3 | 56 | 710 | 7.5 | 3 | 5 | 84 | 2.0 |
5SA450 | 5SA450SM | 5 | 4.5...5.5 | 6 | 450 | +/-3 | 57 | 705 | 6.7 | 3 | 5 | 85 | 2.0 |
5SA500 | 5SA500SM | 5 | 4.5...5.5 | 6 | 500 | +/-3 | 59 | 705 | 6.0 | 3 | 2 | 85 | 1.0 |
5SA600 | 5SA600SM | 5 | 4.5...5.5 | 6 | 600 | +/-3 | 70 | 700 | 5.0 | 3 | 6 | 85 | 1.5 |
5SA700 | 5SA700SM | 5 | 4.5...5.5 | 6 | 700 | +/-3 | 76 | 725 | 4.3 | 3 | 5 | 82 | 1.4 |
5SA800 | 5SA800SM | 5 | 4.5...5.5 | 6 | 800 | +/-3 | 83 | 720 | 3.8 | 3 | 3 | 83 | 1.0 |
5SA900 | 5SA900SM | 5 | 4.5...5.5 | 6 | 900 | +/-3 | 90 | 735 | 3.3 | 3 | 5 | 81 | 1.0 |
5SA1000 | 5SA1000SM | 5 | 4.5...5.5 | 6 | 1000 | +/-3 | 95 | 740 | 3.0 | 3 | 5 | 81 | 0.5 |
SERIES 12SA
Standard Models (25°C ambient, Vi, nom and Pout, Max.) |
PICO PART # | INPUT VOLTAGE
(Vdc) | OUTPUT
VOLTAGE | INPUT
CURRENT | MAX.
OUTPUT
CURRENT
(mA) | MAX.
OUTPUT
POWER
(W) | LOAD
EFFECT
(%) | EFF.
(%) | OUTPUT
RIPPLE
(%) |
Plug-In | Surface Mount | NOM TD> | RANGE | O.V.
SHDN | NOM
(Vdc) | TOL
(%) | NO
LOAD
(mA) | FULL
LOAD
(mA) |
12SA100 | 12SA100SM | 12 | 10...14 | 14.5 | 100 | +/-3 | 41 | 290 | 30.0 | 3 | 3 | 86 | 1.0 |
12SA150 | 12SA150SM | 12 | 10...14 | 14.5 | 150 | +/-3 | 41 | 290 | 20.0 | 3 | 6 | 86 | 1.0 |
12SA200 | 12SA200SM | 12 | 10...14 | 14.5 | 200 | +/-3 | 44 | 292 | 15.0 | 3 | 6 | 86 | 1.3 |
12SA250 | 12SA250SM | 12 | 10...14 | 14.5 | 250 | +/-3 | 43 | 302 | 12.0 | 3 | 4.5 | 83 | 1.2 |
12SA300 | 12SA300SM | 12 | 10...14 | 14.5 | 300 | +/-3 | 42 | 298 | 10.0 | 3 | 3.5 | 84 | 0.75 |
12SA350 | 12SA350SM | 12 | 10...14 | 14.5 | 350 | +/-3 | 42 | 300 | 8.6 | 3 | 3.5 | 83 | 1.4 |
12SA400 | 12SA400SM | 12 | 10...14 | 14.5 | 400 | +/-3 | 39 | 295 | 7.5 | 3 | 5 | 85 | 1.5 |
12SA450 | 12SA450SM | 12 | 10...14 | 14.5 | 450 | +/-3 | 39 | 295 | 6.7 | 3 | 6 | 85 | 2.0 |
12SA500 | 12SA500SM | 12 | 10...14 | 14.5 | 500 | +/-3 | 40 | 298 | 6.0 | 3 | 4 | 84 | 1.0 |
12SA600 | 12SA600SM | 12 | 10...14 | 14.5 | 600 | +/-3 | 40 | 300 | 5.0 | 3 | 2 | 83 | 1.0 |
12SA700 | 12SA700SM | 12 | 10...14 | 14.5 | 700 | +/-3 | 45 | 305 | 4.3 | 3 | 4 | 82 | 1.4 |
12SA800 | 12SA800SM | 12 | 10...14 | 14.5 | 800 | +/-3 | 46 | 308 | 3.8 | 3 | 6 | 81 | 1.0 |
12SA900 | 12SA900SM | 12 | 10...14 | 14.5 | 900 | +/-3 | 46 | 310 | 3.3 | 3 | 7 | 81 | 1.0 |
12SA1000 | 12SA1000SM | 12 | 10...14 | 14.5 | 1000 | +/-3 | 47 | 310 | 3.0 | 3 | 8 | 81 | 0.75 |
SERIES 24SA
Standard Models (25°C ambient, Vi, nom and Pout, Max.) |
PICO PART # | INPUT VOLTAGE
(Vdc) | OUTPUT
VOLTAGE | INPUT
CURRENT | MAX.
OUTPUT
CURRENT
(mA) | MAX.
OUTPUT
POWER
(W) | LOAD
EFFECT
(%) | EFF.
(%) | OUTPUT
RIPPLE
(%) |
Plug-In | Surface Mount | NOM | RANGE | O.V.
SHDN | NOM
(Vdc) | TOL
(%) | NO
LOAD
(mA) | FULL
LOAD
(mA) |
24SA100 | 24SA100SM | 24 | 21...27 | 28 | 100 | +/-3 | 19 | 145 | 30.0 | 3 | 6 | 86 | 1.0 |
24SA150 | 24SA150SM | 24 | 21...27 | 28 | 150 | +/-3 | 20 | 145 | 20.0 | 3 | 6 | 86 | 1.0 |
24SA200 | 24SA200SM | 24 | 21...27 | 28 | 200 | +/-3 | 20 | 150 | 15.0 | 3 | 6 | 83 | 1.3 |
24SA250 | 24SA250SM | 24 | 21...27 | 28 | 250 | +/-3 | 21 | 153 | 12.0 | 3 | 5 | 82 | 1.2 |
24SA300 | 24SA300SM | 24 | 21...27 | 28 | 300 | +/-3 | 21 | 155 | 10.0 | 3 | 5 | 81 | 1.0 |
24SA350 | 24SA350SM | 24 | 21...27 | 28 | 350 | +/-3 | 22 | 156 | 8.6 | 3 | 4 | 80 | 1.4 |
24SA400 | 24SA400SM | 24 | 21...27 | 28 | 400 | +/-3 | 18 | 147 | 7.5 | 3 | 5 | 85 | 1.5 |
24SA450 | 24SA450SM | 24 | 21...27 | 28 | 450 | +/-3 | 19 | 148 | 6.7 | 3 | 6 | 84 | 2.0 |
24SA500 | 24SA500SM | 24 | 21...27 | 28 | 500 | +/-3 | 20 | 148 | 6.0 | 3 | 4 | 84 | 1.0 |
24SA600 | 24SA600SM | 24 | 21...27 | 28 | 600 | +/-3 | 20 | 148 | 5.0 | 3 | 7 | 84 | 1.2 |
24SA700 | 24SA700SM | 24 | 21...27 | 28 | 700 | +/-3 | 23 | 149 | 4.3 | 3 | 4 | 84 | 1.4 |
24SA800 | 24SA800SM | 24 | 21...27 | 28 | 800 | +/-3 | 23 | 150 | 3.8 | 3 | 6 | 83 | 1.0 |
24SA900 | 24SA900SM | 24 | 21...27 | 28 | 900 | +/-3 | 24 | 150 | 3.3 | 3 | 7 | 83 | 1.0 |
24SA1000 | 24SA1000SM | 24 | 21...27 | 28 | 1000 | +/-3 | 24 | 150 | 3.0 | 3 | 6 | 83 | 0.75 |
SERIES 28SA
Standard Models (25°C ambient, Vi, nom and Pout, Max.) |
PICO PART | INPUT VOLTAGE
(Vdc) | OUTPUT
VOLTAGE | INPUT
CURRENT | MAX.
OUTPUT
CURRENT
(mA) | MAX.
OUTPUT
POWER
(W) | LOAD
EFFECT
(%) | EFF.
(%) | OUTPUT
RIPPLE
(%) |
Plug-In | Surface Mount | NOM | RANGE | O.V.
SHDN | NOM
(Vdc) | TOL
(%) | NO
LOAD
(mA) | FULL
LOAD
(mA) |
28SA100 | 28SA100SM | 28 | 25...30 | 31 | 100 | +/-3 | 20 | 129 | 30.0 | 3 | 6 | 83 | 1.0 |
28SA150 | 28SA150SM | 28 | 25...30 | 31 | 150 | +/-3 | 20 | 129 | 20.0 | 3 | 6 | 83 | 1.0 |
28SA200 | 28SA200SM | 28 | 25...30 | 31 | 200 | +/-3 | 21 | 132 | 15.0 | 3 | 6 | 81 | 1.3 |
28SA250 | 28SA250SM | 28 | 25...30 | 31 | 250 | +/-3 | 21 | 133 | 12.0 | 3 | 5 | 81 | 1.2 |
28SA300 | 28SA300SM | 28 | 25...30 | 31 | 300 | +/-3 | 22 | 133 | 10.0 | 3 | 6 | 81 | 1.0 |
28SA350 | 28SA350SM | 28 | 25...30 | 31 | 350 | +/-3 | 22 | 134 | 8.6 | 3 | 4 | 80 | 1.4 |
28SA400 | 28SA400SM | 28 | 25...30 | 31 | 400 | +/-3 | 18 | 127 | 7.5 | 3 | 5 | 84 | 1.5 |
28SA450 | 28SA450SM | 28 | 25...30 | 31 | 450 | +/-3 | 19 | 128 | 6.7 | 3 | 6 | 84 | 2.0 |
28SA500 | 28SA500SM | 28 | 25...30 | 31 | 500 | +/-3 | 20 | 129 | 6.0 | 3 | 4 | 83 | 1.0 |
28SA600 | 28SA600SM | 28 | 25...30 | 31 | 600 | +/-3 | 20 | 130 | 5.0 | 3 | 5 | 82 | 1.5 |
28SA700 | 28SA700SM | 28 | 25...30 | 31 | 700 | +/-3 | 23 | 127 | 4.3 | 3 | 4 | 84 | 1.4 |
28SA800 | 28SA800SM | 28 | 25...30 | 31 | 800 | +/-3 | 23 | 127 | 3.8 | 3 | 6 | 84 | 1.0 |
28SA900 | 28SA900SM | 28 | 25...30 | 31 | 900 | +/-3 | 24 | 128 | 3.3 | 3 | 7 | 84 | 1.0 |
28SA1000 | 28SA1000SM | 28 | 25...30 | 31 | 1000 | +/-3 | 24 | 128 | 3.0 | 3 | 6 | 84 | 1.0 |
